Mercury Quick Attack Mounting Bracket Assembly

Mercury Quick Attack™ LE Monitor Style 3444 Specifications

The 500 gpm portable monitor shall meet NFPA 1964, 2018 and EN-15767-1. The quick attack monitor shall be lightweight and compact in size. It shall have a 2 1/2" inlet with a full time swivel and a 2 1/2" outlet. The monitor should weigh no more than 15 pounds or 6.8 kg less the nozzle, and have dimensional layout of 9.6"H x 15.0"L x 23.5W (deployed). The monitor shall have a maximum operating pressure of 230 psi or 16 bar. The legs shall fold away to reduce the width down to 7.75". The monitor shall have + 10° of rotation and 50° to 30° elevation range for unmanned use. The handle shall consist of a spring-loaded mechanism that lets the user travel down to 10° of elevation for manned use. The legs shall have a T design and have carbide tip spikes. The monitor shall have a safety strap with integrated bag and hook that is mounted to the monitor and can be hooked to itself to be used as a carrying strap. The  monitor mounting bracket shall have the ability hold the monitor with an Akron Brass adjustable/selectable nozzle, Akron Brass fixed orifice nozzle, Akron Brass oscillating nozzle or Akron Brass smooth bore deluge tip. The monitor shall have an unobstructed waterway with a friction loss no more than 6psi at full flow. It shall have a ball shut-off valve with the Akron Tork–Lok mechanism. The material shall be of Pyrolite® construction with the Akro-Tec coating and chrome trim. The outlet shall have a reflective band for night visibility.
